SLTN RP anti-rodent fiber optic cable cross-section showing glass yarn rodent barrier
SLTN RP anti-rodent cable structure detail
Outdoor Fiber Optic Cable

SLTN RP Non-Metallic Anti-RodentFiber Optic Cable

Specialized non-metallic anti-rodent cable with FRP core and glass yarn rodent barrier. 2–144 cores for underground and duct deployment in rodent-prone environments with dry cable core design.

Cable TypeSLTN RP (Non-Metallic, Anti-Rodent)
Fiber Count2–144 cores
Attenuation @1310nm≤0.36dB/km
Attenuation @1550nm≤0.22dB/km
Rated Tensile Strength4000–4500N (short-term), 600–1500N (long-term)
Operating Temperature-40°C to +70°C
Specifications

Technical Specifications

Cable Type
SLTN RP (Non-Metallic, Anti-Rodent)
Fiber Count
2–144 cores
Fiber Type
G.652D single-mode
Installation
Duct, underground
Attenuation @1310nm
≤0.36dB/km
Attenuation @1550nm
≤0.22dB/km
Cable Diameter
10.5–16.3mm
Weight
90–220 kg/km
Rated Tensile Strength
4000–4500N (short-term), 600–1500N (long-term)
Crush Resistance
3000N/100mm (short-term), 1000N/100mm (long-term)
Operating Temperature
-40°C to +70°C
Strength Member
FRP central strength member
Construction
Non-metallic core, glass yarn anti-rodent
Jacket Material
PE outer sheath with swell water-blocking tape
Standards
IEC 60794-1 · YD/T 901
Certifications
ISO9001 · ISO14001 · CE · RoHS

Quote checklist

Confirm the configuration for Anti-Rodent Fiber Optic Cable

Your quote is faster and more accurate when the required quantity, installation conditions, and the configuration below are included with the request.

Cable Type
SLTN RP (Non-Metallic, Anti-Rodent)
Fiber Count
2–144 cores
Fiber Type
G.652D single-mode
Installation
Duct, underground
Key Features

Engineered For Performance

Specialized Anti-Rodent Jacket

Glass yarn anti-rodent element integrated into the cable structure provides proven resistance to rodent gnawing, tested and validated for high rodent activity environments.

Non-Metallic Design

FRP core and non-metallic construction eliminate lightning damage risk and electromagnetic interference, combining anti-rodent protection with electrical safety.

Dry Cable Core

Swell water-blocking tape replaces traditional filling compound, reducing cable weight and making installation and splicing cleaner and faster.

High Crush Resistance

3000N/100mm short-term crush resistance provides robust mechanical protection for underground and duct installations.

Typical Applications

01

Rodent-Infested Underground Routes

Primary solution for fiber deployment in areas with severe rodent problems, including agricultural fields, forests, and urban environments with pest activity.

02

Non-Metallic Duct Networks

Underground duct installations requiring both anti-rodent protection and non-metallic construction for lightning safety in exposed environments.

03

Critical Service Protection

Fiber links for essential services (hospitals, emergency systems, government networks) where rodent-induced outages are unacceptable.
