OM2 Multimode 50/125μmFiber Optic Patch Cord
OM2 multimode 50/125μm fiber patch cord with orange jacket. For 1G ethernet up to 550m distance. Available with LC and SC connectors.
Technical Specifications
Quote checklist
Confirm the configuration for OM2 Multimode Patch Cord
Your quote is faster and more accurate when the required quantity, installation conditions, and the configuration below are included with the request.
- Connector Type
- LC, SC (Any combination)
- Fiber Mode
- Multimode OM2 (50/125μm)
- Fiber Count
- Simplex / Duplex
- Cable Diameter
- 2.0mm / 3.0mm
Engineered For Performance
50μm Core Performance
50/125μm core provides 2.5x the bandwidth of OM1 (62.5μm), supporting 1G Ethernet up to 550m with standard VCSEL transceivers.
Cost-Effective 1G Solution
Lower cost than OM3/OM4 while still providing adequate bandwidth for 1000BASE-SX applications within typical campus distances.
Standards Compliant
Meets TIA-568 and IEC standards for multimode fiber patch cords, ensuring interoperability with third-party equipment and connectors.
Typical Applications
1G Ethernet Networks
1000BASE-SX connections up to 550m in campus and building backbone applications where 10G speeds are not required.
Legacy Data Center Patching
Equipment jumpers and cross-connects in data centers with existing OM2 fiber infrastructure.
