LCFiber Optic Connector — UPC, APC, Single Mode & Multimode
LC fiber optic connector with 1.25mm zirconia ferrule and push-pull latching mechanism. Available in UPC and APC polish types for single mode and multimode applications. Compact small form factor design for high-density patching environments.
Technical Specifications
Quote checklist
Confirm the configuration for LC Connector
Your quote is faster and more accurate when the required quantity, installation conditions, and the configuration below are included with the request.
- Connector Type
- LC/UPC, LC/APC
- Ferrule Diameter
- 1.25mm
- Ferrule Material
- Zirconia Ceramic
- Fiber Mode
- SM 9/125μm, MM 50/125μm, MM 62.5/125μm
Engineered For Performance
Compact Small Form Factor
1.25mm ferrule design allows twice the port density of SC connectors, making LC the standard choice for high-density data center and telecom patching environments.
Ultra-Low Insertion Loss
Precision-polished zirconia ceramic ferrule delivers typical insertion loss of 0.2dB or less, ensuring minimal signal degradation across long fiber links.
Push-Pull Latching Mechanism
Secure push-pull latch enables quick, tool-free connections and disconnections even in tight spaces, reducing installation time and preventing accidental disconnection.
Dual Polish Options
Available in UPC (≥50dB return loss) and APC (≥60dB return loss) polish types, supporting both standard data networking and demanding analog/CATV applications.
Typical Applications
Data Center Patching
High-density LC duplex connections for 10G, 25G, and 100G SFP/QSFP transceiver modules in top-of-rack and leaf-spine architectures.
Telecom Access Networks
LC connectors in OLT and ONU equipment for GPON/XGS-PON deployments, providing reliable connections at central offices and subscriber endpoints.
Enterprise LAN Cabling
Structured cabling backbone and horizontal runs in office buildings, hospitals, and campus networks requiring compact, high-performance fiber connectivity.
Interested in this LC Connector?
Tell us your quantity, cable length, and any custom requirements. Our engineering team will respond with a detailed quote within 24 hours.
